Commando AIR-APO300 Outdoor Access Point
| Brand | COMMANDO |
|---|---|
| Warranty | 6-Month Warranty |
AIR-APO300
COMMANDO Air ONE 0300Mbps, 2.4GHz, 802.11n, MIMO, Multi-Mode, Outdoor Access Point
- Multiple Operational Modes like Gateway, Repeater, WISP, Super WDS, AP. All COMMANDO AirONE series Outdoor AP default mode is AP mode.• Supports Multi SSID up to 4 with inbuilt WI-FI channel analysis.• Supports IEEE 802.11b/g/n, 2.4GHz, MIMO High Gain Omni 5dBi Internal Antenna with RF input Power up to 1000mW.• Support wireless RF power adjustable as per user movements from APO.• Wireless clients up to 64 max, with concurrent end users up to 50.• Support tag VLAN and VLAN management.• Supports intelligent load balance based on users.• Support seamless roaming and low-rate terminal access.• Dual purposes WAN or 24V POE supporting 1x 10/100Mbps.• Dedicated LAN ports 1x 10/100Mbps.• Supports Wi-Fi client distance around 70 meters radius depending on surrounding conditions.• Dual input for power either 24V POE or 12V, 1.5A DC power inputs.• Support Open or encryption like WPA/WPA2PSK_TKIPAES• Plug and Play design with self-adaption with Zero Touch Provisioning.• Compact IP65 casing, silent design perfect for noise sensitive environments.• Affordable, Easy-to-Use AP for Small Business Networks, with Zero Configuration Required.• Built-in High-Performance Processor with long life, Suitable for Deployment of Large Scale Commercial Scenarios• Comes with one-year default warranty – optionally extendable up to 3 years.
SOFTWARE HIGHLIGHTS
Home
Device Information like CPU Usage, Memory Usage, LAN Information like IP Mode Get IP From AC/Gateway/Static, Status with 2G Wi-Fi Clients Status with information like SSID, Channel, Bandwidth, Encrypt, MAC Address, Operation Mode configure like AP/ Fat AP Mode with Uptime, Flow in bps for AP Downstream and AP Upstream.
Wizard
Gateway Mode, Super WDS Mode, Repeater Mode, WISP Mode, AP Mode (Default Selection).
Wi-Fi
2G Wi-Fi Status ON/OFF, SSID, Hide your SSID, Bandwidth, Channel, Encryption Open/Encryption with WPA/WPA2PSK_TKIPAES, MAC ACL with Add, Delete, Apply with disable/Allow/ Prohibit option, Wi-Fi Timer Off/ON with Time Frame, Advanced setting like Country Region, 2G Channel (1-13), Multicast Fast, Maximum client for per AP (Range 1-64), WLAN Partition, Short GI, Coverage Threshold(-95dBm~-65dBm), TX Power, DFS.
Network
LAN Settings with DHCP server option, Static DHCP, VLAN Settings & Cloud Server Settings.
Security
URL Filter, IP Filter, MAC Filter & DMZ Settings.
Manage
Configure, Reboot, Modify Password, Upgrade, Time, Log, Flow Control, IP Group, Time Group & DDNS Settings.
